PCB layout, fabrication, conventional & surface mount assembly

elatec s.r.o. is one of the leading manufacturers of professional and consumer electronic products in Slovakia. We specialize in electronic development, circuit design, PCB layout, prototyping, programming - All the parts of Electronics Research and Development needed to build a new product. Our main services include printed circuit board fabrication, PCB assembly, cable assembly, CAD engineering.

The client specifies the project and we design the electronics, the PCBs are subcontract assembled and delivered to our clients as the final products.

elatec s.r.o. has been specialized in manufacturing Single-Sided Boards and Double-Sided Boards, our main goal is manual PCB design of analog PCB`s.


PCB design


PCB fabrication

  • Single-Sided Boards, Double-Sided Boards
  • Maximal format of panel 600x450mm
  • GERBER, EXCELLON data
  • Minimal conductor spacing (gap):
    • 0,2mm (8mil) for 18µm thickness of copper foil
    • 0,254mm (10mil) for 35µm thickness of copper foil
  • Minimal trace width (drawing width):
    • 0,2mm (8mil) for 18µm thickness of copper foil
    • 0,254mm (10mil) for 35µm thickness of copper foil
  • Minimal pad – diameter of hole+0,4mm
  • Minimum drill diameter 0,3 mm
  • Cooper laminate thickness: 18, 35, 70, 105µm
  • Manual routing, our goal is an analog PCB design
  • SMT & Through-hole technology
  • Output data GERBER, EXCELLON
  • Solder mask, Silk screen,
  • Surfaces – HAL SnPb, Lead Free HAL (Balverz) or chemical tin
  • Metalization by Au – contact, segment
  • Electrical test by Fly Probe tester
  • Min. quantity of boards - equivalent one technological panel of format A4 (200x300mm)

  • Multi-layer PCB`s
  • SMT & Through-hole technology
  • Quick-turn Prototypes
  • Input data GERBER, EXCELLON
  • Solder mask, Silk screen
  • RoHS & Pb-Free compliance
  • Prototypes to large volume production
  • 100% Netlist Testing
  • Visual inspection for defects




















PCB assembly



  • Wave and manual soldering
  • SMT & Through-hole technology
  • high speed pick and place machines
  • Prototype & Volume Production
  • Quick-Turn Assemblies
  • RoHS & Pb-Free compliance
  • Visual inspection
  • Low, medium and high volume production


We have been satisfying our clients in theirs design and manufactuting needs for over 20 years and we are looking forward to serving you in any of your PCB needs
